Adapteris Manhattan RS-232 x 2, USB

Prekės aprašymas anglų kalba:

Easily connect serial devices through a USB port.

Most modern computers and laptops don't have RS232 (DB9) ports, making the use of legacy peripherals and high-tech devices which connect with COM ports almost impossible. The Manhattan USB to Serial Converter — with its serial RS232 (DB9) ports and Prolific PL-2303RA chipset — easily expands a single USB port to connect and support serial modems, barcode scanners, digital cameras, card readers, Ham/Amateur Radios, GPS, CNC machines, telescopes, embroidery machines, fuel injection controllers, PDUs, network switches and other devices.

Quality Construction and Easy Installation

Gold-plated contacts and rugged construction combine to offer a reliable connection between the computer and serial peripherals for consistent, trouble-free performance. Windows compatibility with plug-and-play installation and hot-swappability help provide seamless use without inconvenient and frustrating device conflicts.

Quickly converts a USB port into two Serial/RS232/COM/DB9 ports

• The customizable and compatible Prolific PL-2303RA chipset makes it the ideal solution for many OSs and platforms

• Easily connect most DB9/serial modems, digital cameras, label writers, barcode scanners, palm PCs, GPS, telescopes, CNC machines, embroidery machines, automotive control systems, digital organizers and much more

• Install as standard COM/RS-232 ports to provide serial connectivity for legacy and high-tech devices

• Chipsets PL-2303HXD and FTDI FT232RL configurations are also available at www.ManhattanProducts.com

• Windows compatible; plug and play; hot-swappable

Standards and Certifcations

CE

FCC

USB 1.0

USB 1.1

RoHS

WEEE

Connections

USB port; type-A male

2 Serial/COM/RS232/DB9 ports; 9-pin male(s)

General

Transfer rate: up to 115 kbps

Bus powered

Overcurrent protection

Prolific PL-2303RA chipset

Physical

Cable length: 45 cm (18 in.)

Weight: 225 g (7.9 oz.)

System Requirements

Windows XP/Vista/7/8/8.1/10 or Linux or Mac 9.x/10.x or above

Package Contents

USB to Serial Converter

Instructionsl and driver CD
